Acetylene torch, induction and resistance heating

Cu48ZnNi9Ag is a high strength brazing alloy, usually used for joints requiring high mechanical resistance characteristics.The addition of silver in the composition refines the alloy, lowers the melting range, improves electrical conductivity, increases ductility and enhances flow properties. Brazing procedures range from manual to induction techniques.

Because of the high zinc content, it is recommended to keep the heating cycle to a minimum to prevent zinc vaporization. When brazing in an oxidizing environment a proper high temperature flux should be used. Typical applications are in general mechanics, joining of tubular elements for various applications, metal furniture industry, bicycle frames, etc.

Rods: φ1.5-5.0mm  Max.Length: 1000mm

Wire:  φ0.8, 1.0, 1.2, 1.6mm on spools D300

Strip

Other dimensions are available upon request

Working temperature: 930-960 °C

Melting range: 890 - 920 °C

Specific gravity: 8.7 g/cm³

Tensile strength: 530 N/mm²

Elongation: 15-20 %
